DM Plant
Backed by a team of well qualified and experienced professionals, we are engaged in offering a wide array of DM Plant to our respected customers.Features :
- Less maintenance
- Light-weight
- Damage resistance
- Excellent strength
- Easy to use
- Simple design
We are leading demineralisation plant and dm plant supplier Kalyan Mumbai. For pure water and ultra-pure water for use as make-up to high-pressure boilers and for use in the pharmaceutical industry, micro-electronics industry and chemical/petrochemical industries, Filtracons Water Systems is available.
Our range of cation and anion exchange units are available in flow rates up to 9.7m³/h. The units employ both normal and counter-flow regeneration. These smaller standard units are:
- skid-mounted
- complete with automatic conductivity instigated regeneration
- central control panel
- Control valves are either the well-proven 5-cycle multiport valve or, for larger units, a frontal manifold with individual corrosion-resistant valves.
The larger units are designed and manufactured to suit the client’s requirements and in keeping with Derwent’s philosophy to purpose-design to suit individual needs and budgets. The larger units typically can cope with flow rates up to 100m³/h.
Acid and caustic used for automatic plant regeneration of the anion and cation streams can be from:
- carboys
- semi-bulk acid
- or bulk acid containers
For ultra-pure water, additional mixed bed polishers can be provided – again depending upon the applications.
Price range :
- 10,000 Rs to 5,00,000 Rs
Effluent Water Treatment Plant
Our Company is one of the famous names in the market for offering a Effluent Water Treatment Plant at very affordable rates.Price range :
- 1,00,000 Rs to 10,00,000 Rs
Commercial RO Water Treatment Plant
Our Company is one of the famous names in the market for offering a wide assortment of Commercial RO Water Treatment Plant at very affordable rates.Price range :
- 8,000 Rs to 25,000 Rs
Softener Plant
Filtracon technology is a Softener plant manufacturer in Kalyan,Mumbai. The presence of hardness salts (calcium and magnesium ions) in the make up water softeners water supplies to boilers, cooling and process waters can have a serious impact on their performance. Loss of heat transfer in boilers and poor cooling in re-circulating cooling systems results in an increase in both energy and water consumption, and an increase in operating costs.
The reliable Filtracon Technology standard range effectively removes these hardness salts and provides a valuable return on your investment.
We are offering highly durable Water Softening Plant that is used for removing hard salts and providing suitable water. The water gets hard when it contains more of calcium and magnesium ions. Softening is the ion exchange process, which is done through resin, is preferred over others plant as it is one of the best possible method for removing from water. Here, undesirable ions are exchanged for ions that are more required. The process comprises of passing the unrefined water containing hardness through a bed of cation resin in sodium form. The hardness ions Ca & Mg are then up by resin and in exchange, the sodium ions are turned down from the resin. This is the service cycle, where the hard water is being softened in this plant.
Hard water can lead to the following water problems:
- Scale build-up in pipes, resulting in decreased flow rates
- Scale build-up on heating and cooling systems, leading to increased electricity costs and breakdowns.
- White film on glass surfaces and staining on water taps
- Increased laundry costs due to hard water reacting with soap and laundry detergents.
The Process :
The heart of a water softener is a mineral tank. It’s Filled with small polystyrene beads, also known as resin or zeolite. The beads carry a negative charge. Calcium and magnesium in water both carry positive charges. This means that these minerals will cling to the beads as the hard water passes through the mineral tank. Sodium ions also have positive charges, albeit not as strong as the charge on the calcium and magnesium.
When a very strong brine solution is flushed through a tank that has beads already saturated with calcium and magnesium, the sheer volume of the sodium ions is enough to drive the calcium and magnesium ions off the beads. Water softeners have a separate brine tank that uses common salt to create this brine solution. In normal operation, hard water moves into the mineral tank and the calcium and magnesium ions move to the beads, replacing sodium ions. The sodium ions go into the water. Once the beads are saturated with calcium and magnesium, the unit enters a 3-phase regenerating cycle. First, the backwash phase reverses water flow to flush dirt out of the tank. In the recharge phase, the concentrated sodium-rich salt solution is carried from the brine tank through the mineral tank. The sodium collects on the beads, replacing the calcium and magnesium, which go down the drain. Once this phase is over, the mineral tank is flushed of excess brine and the brine tank is refilled.
Industries Who use Softener Plant :
- Boiler Feed
- Cooling Tower Make-Up
- Air Conditioning Plant
- Textile Processing
- Beverage Production
- Hospitals, Hotels, Laundries etc.
Treated Water Quality :
Rain Water Harvesting Plant
Filtracon Technology Pvt Ltd is one of the longest established and leading manufacturers of rainwater harvesting and greywater recycling systems in the Mumbai,India.
With 5 years of in-house experience in this market, we pride ourselves in offering a complete package to Designers, Consultants, Mechanical Contractors, Building Contractors, Civil Engineering Contractors and end users in both the Commercial and Domestic market.
We offer :
- Detailed design,
- System supply,
- Installation,
- Maintenance and
- A full after sales service package
- Free initial design assistance
ETP Plant
Industrial process generates a huge quantity of high toxic effluents which yield very high BOD, COD, TS and TDS level with black coloured and odour effluent.
On the basis of the above mentioned fact, we have developed a Zero Liquid Discharge Effluent Treatment system by which it will be possible to overcome these issues that affects all our environment. Our concepts involve the treatment which is based on the belief that all the BOD requirement should go down and the condensate coming out should be non- polluted.
We have developed a process for treatment of industrial effluent with economical operation and ensuring a Zero Liquid Discharge.
Through our ETP Plant we provide you :
- Totally integrated zero discharge system.
- By Product is marketable commodity in most of the cases.
- Almost complete use of water.
- Our ETP plants are compact and requires very less space.
- User friendly plant.
- Lowest Operation & Maintenance Cost.
- Our design is flexible and the Effluent Treatment Plant can be easily upgradeable.
Price range :
- 1,00,000 Rs to 10,00,000 Rs
Sea Water Treatment Plant
Price range :
- 25,000 Rs to 5,00,000 Rs
Industrial Water Treatment Plant
Price range :
- 25,000 Rs to 5,00,000 Rs
